AWP604C - Portable PA System with Rechargeable Battery and TWO Wireless Microphones

AWP604C





AWP604C-L





AWP604C-M






FEATURES

AWP604C FRONT VIEW

AWP604C TOP VIEW



HANDHELD MICROPHONE



SPECIFICATIONS



ACCESSORIES





The Audio2000'S AWP604C portable all-in-one PA system is a portable self-contained PA system containing an 1.3AHr rechargeable battery, TWO wireless microphones, a built-in amplifier, a speaker, and a heavy-duty carrying bag.  The above dual-channel wireless microphone system includes the combination of two handheld microphones, one handhled microphone and one belt-pack set (including a body-pack wireless transmitter, a headset microphone, and a lavaliere microphone), or two belt-pack sets.  An AUX input connector and an AUX output connector are provided to have the AWP604C be able to be used with any other PA or audio system.  An 1/4” connector is provided to be used as an electric guitar input or a microphone input.  The combination of the built-in amplifier and the speaker of the AWP604C provides  30W power output to achieve effective PA applications.  A carrying bag is provided for portability and mobility of the AWP604C.  Overall, the AWP604C is designed and manufactured to be a versatile, user-friendly, convenient and reliable system.

APPLICATIONS

School Teacher, Church, Hotel Conference Room, Aerobics Instructor, Sport Coach, Auction, Street Musician and Any Small Meeting Room

Back To Top

FEATURES

  • Built-in 12VDC 1.3AH Rechargeable Battery
  • 30W Power Output
  • Two Wireless Microphones and Built-in Wireless Receiver
  • Wireless Microphone Volume Control
  • One 1/4" Microphone Input
  • 1/4" Microphone Volume Control
  • Tone Control Knob
  • Echo Control Knob
  • One Heavy-Duty Back-Pack-Style Carrying Bag

Back To Top

AWP604C FRONT VIEW


Click here to enlarge the above image.

Back To Top

AWP604C TOP VIEW


Click here to enlarge the above image.

Back To Top

HANDHELD MICROPHONE

Back To Top

SPECIFICATIONS

Wireless Transmitter:

Carrier Frequency

VHF

Transmission Power Less Than 30mW

Transmission Mode

FM

Power Consumption

70mA, Max.

Battery

9V (or 8.4V Rechargeable Battery)

Wireless Receiver:

Audio Output Power

30W

S/N Ratio

> 60dB

Frequency Response

100 - 12,000 Hz

Sensitivity

10dBuV

Recharge Time

8 Hrs

Battery Capacity

3 Hrs (12VDC, 1.2AH)

Service Range

100ft (30M)

Dimensions (W X D X H) 180 X 110 X 290mm (7.1" X 4.3" X 11.4")

Back To Top

ACCESSORIES

              ITEMS                                                                                        QUANTITIES
        AWP604C Unit (Black)                                                                               1
        Quantity of Handheld Microphones
                           or
                           Body-Pack Transmitters +  lavalier Microphones                   2
        Owner's Manual                                                                                         1
        Heavy-Duty Carrying Bag                                                                          1

  Back To Top
