APA9260 - 3200W Professional Power Amplifier





The Audio2000'S APA9260 system is a professional power amplifier specifically designed and developed for delivering sufficient direct sound power in a variety of acoustic environments.

All three of the balanced XLR, balanced 1/4" TRS and unbalanced RCA input jacks are utilized as input jacks while the 1/4" jacks, Speakon jacks and the banana (binding post) jacks are used for the speaker outputs.

In addition,  the Stereo / Mono-Bridge select switch allows the users to utilize the power amplifier as a stereo one or a bridged mono power amplifier.   There are also numerous built-in performance features such as built-in signal current and signal voltage limiters, and soft-start power-on.

The extraordinary features of quality sound with extremely low distortion, versatile performances and function, and rugged/delicate appearance make the APA9260 professional power amplifier an outstanding value in any critical project recording or live applications.



APPLICATIONS

Project recording and live applications



FEATURES CONFIGURED TO BE USER FRIENDLY

  • 1/4" TRS and XLR balanced inputs / RCA unbalanced inputs
  • 1/4", Speakon and banana jack speaker outputs
  • Large Size cooling fanl
  • Switchable Sub Filters (Low Cut Filters) for eliminating speaker resonance
  • Level control for each channel
  • Noise-free Power On/Off
  • Built-in DC-offset, short circuit and speaker protection
  • Built-in signal current limiter and signal voltage limiter
  • 115V / 230V AC Voltage selector



SPECIFICATIONS

INPUTS Balanced: One XLR Jack, One 1/4" TRS Phone Jack for Each Channel
Unbalanced: One RCA Jack for Each Channel
OUTPUTS One 1/4" Jack, Speakon Jack and Banana Jack (Binding Post) for Each Channel
OUTPUT POWER 3200W (Max) @ 2 Ohms / 600W (RMS) X2 @ 8 Ohms
LOWEST OUTPUT LOAD IMPEDANCES 2 Ohms (stereo) / 4 Ohms (Bridged)
FREQUENCY RESPONSE 5 - 40,000 Hz, +/-  0.5dB
SIGNAL-TO-NOISE RATIO (IEC-A) > 94 dB
T.H.D. < 0.05%
INDICATORS Power/On, Signal
COOLING Large Cooling Fan
DIMENSIONS 19" x 5.2" x 11.8" (481 x 132 x 300 mm)
WEIGHT 46 lb (21 Kg)
