AWM6031DU - UHF Single-Channel Diversity
Wireless Microphone Systems
The Audio2000'S® AWM6031DU
wireless system is a UHF single-channel
diversity wireless microphone system. Similar to
the other Audio2000'S®
wireless systems, various transmitter options are
provided to the AWM6031DU system users as follows:
Handheld Wireless
Microphone System -
AWM6031DU (AWR6031DU + AWX6030)
Lavaliere
Wireless Microphone
System -
AWM6031DUM (AWR6031DU + AWX6030M)
Headset
Wireless Microphone
System - AWM6031DUH (AWR6031DU +
AWX6030H)
Guitar/Instrument
Wireless System - AWM6031DUG (AWR6031DU + AWX6030G)
With the exceptional RF transmission and reception, the AWM6031DU
system, with a transmission range of more than 150 feet, fully delivers all the reception
and audio quality features that allow you to really enjoy the freedom of wireless without
any of the problems.
Engineered For Dependable UHF Systems
As all the other Audio2000'S® wireless products, the
AWM6031DU system has been engineered to be dependable UHF system with a wide audio
frequency range, high S/N ratio, and outstanding performance equal to that of any
professional wireless systems costing much more. This is achieved through strict
component selection and high quality circuit design. A delicately designed silence
circuit eliminates static noise when the transmitters are either turned off or out of
transmission range. An auto mute circuit is incorporated in these systems to
effectively eliminate the popping noise when the switch is turned on or off.
System Designed For Accessibility
The AWM6031DU system has been designed and manufactured to be
dependable, problem free, versatile and easy to use. The AWM6031DU system is
intended to be readily accessible to everyone with exceptional performance at a preferred
and affordable price.
APPLICATIONS
Musician; disc jockey (DJ); karaoke jockey (KJ); church; school;
conference room; karaoke; home entertainment
AWR6031DU RECEIVER
FEATURES
* UHF Band Frequency
* One XLR Balanced Output
and One 1/4"
Unbalanced Audio Output
* RF Input with Built-in RF Preamplifier to Improve S/N Ratio, Sensitivity
and Dynamic Range
* Low Noise Mixer Circuitry for Reducing interference
* Squelch Control at the Rear Panel
* Diversity Receiver for Optimal Reception
* 12V-18V DC Power Supply
SPECIFICATIONS
|
Carrier Frequency Range |
571
- 598 MHz |
|
Frequency Stability |
±
0.005% |
|
Receiving Sensitivity |
-105 dBm |
|
S/N Ratio |
80
dB |
|
T.H.D. |
< 1% |
|
Audio Output |
¼” and XLR (0 – 300mV @
600 Ohms) |
|
Dimensions (W X H X D) |
8.5” X 1.6” X 5.4” (215 X
40 X 138 mm) |
AWX6030,
AWX6030M, AWX6030H & AWX6030G
TRANSMITTERS
FEATURES
* UHF Band Frequency
* High Sensitivity Cardioid Microphone Capsule
* Audio Level Adjustment Knob for the AWX6030M, AWX6030H,
and AWX6030G
* Noise Reduction Mechanism for Eliminating Handling Noise and Switch Shock
Noise
* Low Battery LED Indicator
SPECIFICATIONS
|
Carrier Frequency Range |
571
- 598 MHz |
|
Frequency Stability |
±
0.005% |
|
Modulation |
Frequency Modulation (FM) |
|
Modulation Depth |
40KHz |
|
Output Power |
30mW, Max |
|
Spurious Emission |
> 55 dB |
|
Battery |
9V Battery |
|
Current Consumption |
< 40 mA |
|
Dimensions (W X H X D)
|
Handheld: 9.3” X 2.0” X
2.0” (235 X 50 X 50 mm)
Belt-Pack: 2.6” X 4.1” X 1.0” (65 X 105 X 25 mm) |
|
Carrier Frequency Range |
571
- 598 MHz |
|
Frequency Stability |
±
0.005% |
|
Audio Frequency Response |
80 – 15,000Hz |
|
Image and Spurious
Rejection |
50
dB Minimum |
|
S/N Ratio |
> 80
dB |
|
Max. SPL |
110
dB |
|
T.H.D. |
< 1% |
|
Service Area |
150 ft (45 M) |
|
Operation Temperature |
14
°F – 122
°F (-10
°C – +50
°C) |
Back to Top
OPERATIONS
SYSTEM OPERATION
(I) HANDHELD
MICROPHONE SYSTEM
-
-
-
-
-
-
-
-
-
-
Place one 9V battery into the battery
housing of the AWX6030M transmitter with the battery polarity oriented
as indicated. Connect the supplied lapel (lavaliere) microphone to the
AWX6030M transmitter.
-
Turn on the power of the AWR6031DU
receiver. The Power On LED light will be turned on.
-
On the AWX6030M, the On/Off switch has
three positions: “ON”, “STDBY” and “OFF”. When the On/Off switch is
turned to the “STDBY” or directly to the “ON” position, the low battery
LED indicator will blink once and then stay off. If the low battery LED
indicator stays on, the 9V battery needs to be replaced. When the On/Off
switch is set to the “STDBY” or “ON” position, the Antenna A or Antenna
B LED light on the AWR6031DU receiver will be turned on. The AF LED
light will be on whenever the lavaliere microphone connected to the
AWX6030M transmitter receives any sound while the On/Off switch is set
to the “ON” position. The audio level adjustment knob is preset at
midpoint. If you need to increase the audio level, use a screwdriver to
turn the audio level adjustment knob clockwise. Turn the audio level
adjustment knob counter-clockwise to reduce the audio level.
-
Adjust the volume control knob on the
AWR6031DU receiver to have an optimal sound quality.
-
-
-
-
Place one 9V battery into the battery
housing of the AWX6030H transmitter with the battery polarity oriented
as indicated. Connect the supplied headset microphone to the AWX6030H
transmitter.
-
Turn on the power of the AWR6031DU
receiver. The Power On LED light will be turned on.
-
On the AWX6030H, the On/Off switch has
three positions: “ON”, “STDBY” and “OFF”. When the On/Off switch is
turned to the “STDBY” or directly to the “ON” position, the low battery
LED indicator will blink once and then stay off. If the low battery LED
indicator stays on, the 9V battery needs to be replaced. When the On/Off
switch is set to the “STDBY” or “ON” position, the Antenna A or Antenna
B LED light on the AWR6031DU receiver will be turned on. The AF LED
light will be on whenever the headset microphone connected to the
AWX6030H transmitter receives any sound while the On/Off switch is set
to the “ON” position. The audio level adjustment knob is preset at
midpoint. If you need to increase the audio level, use a screwdriver to
turn the audio level adjustment knob clockwise. Turn the audio level
adjustment knob counter-clockwise to reduce the audio level.
-
Adjust the volume control knob on the
AWR6031DU receiver to have an optimal sound quality.
-
-
-
-
Place one 9V battery into the battery
housing of the AWX6030G transmitter with the battery polarity oriented
as indicated. Connect the supplied guitar to the AWX6030G transmitter.
-
Turn on the power of the AWR6031DU
receiver. The Power On LED light will be turned on.
-
On the AWX6030G, the On/Off switch has
three positions: “ON”, “STDBY” and “OFF”. When the On/Off switch is
turned to the “STDBY” or directly to the “ON” position, the low battery
LED indicator will blink once and then stay off. If the low battery LED
indicator stays on, the 9V battery needs to be replaced. When the On/Off
switch is set to the “STDBY” or “ON” position, the Antenna A or Antenna
B LED light on the AWR6031DU receiver will be turned on. The AF LED
light will be on whenever the guitar or any electrical instrument
connected to the AWX6030G transmitter generates sound while the On/Off
switch is set to the “ON” position. The audio level adjustment knob is
preset at midpoint. If you need to increase the sound level, use a
screwdriver to turn the audio level adjustment knob clockwise. Turn the
audio level adjustment knob counter-clockwise to reduce the sound level.
-
Adjust the volume control knob on the
AWR6031DU receiver to have an optimal sound quality.
OPERATION NOTES
- The AWX6030,
AWX6030M, AWX6030H, or AWX6030G needs to be turned off before changing
the 9V battery.
- Signal dropout or
unexpected noise may be caused by a low battery or by an excessive
distance between the transmitter and the receiver. If you encounter
signal dropout or unexpected noise, please check the battery first. If
battery is still fresh, try to readjust the antennas on the AWR6031DU
receiver.
- Avoid placing the
receiver in a corner to prevent any RF reception deterioration.
- Avoid placing the
receiver antennas close to an obstruction or close to any metal surface.
- Try to place the
receiver as far away from any digital equipment, including computers and
some CD players, as possible.
- If more than one
AWM6031DU wireless microphone systems are stacked together or placed in
a rack, do not let the antennas touch each other or cross each other.
- Before the
AWM6031DU is to be used in a new location, place the AWR6031DU receiver
at the intended location and walk-through the area with the transmitter
to locate any radio frequency blind spot, where a momentary loss of
sound or short period of noise may occur whenever the transmitter is
moved to this spot.
- Do not drop the
transmitter on the floor or strike the transmitter with any object.
- Always turn off
the transmitter and remove the battery if the transmitter is not to be
used for a period of time to prevent the transmitter from being damaged
by a leaking battery.
Back to Top
TROUBLESHOOTING
PROBLEM
|
POSSIBLE CAUSES
|
SOLUTIONS
|
|
No sound. |
Receiver is
off. |
Turn on
receiver. |
|
Transmitter
power switch is off. |
Turn on
transmitter power switch. |
|
No battery or
bad battery in transmitter. |
Insert or
replace battery. |
|
Wrong polarity
or faulty battery contact |
Correct
polarity or battery contact. |
|
Receiver audio
cable is missing or defective. |
Connect, repair
or replace cable. |
|
Short range or
signal dropouts. |
Low transmitter
battery level. |
Replace
transmitter batteries. |
|
Poor antenna
reception. |
Reposition
antenna or receiver. |
|
Faulty
transmitter antenna. |
Return
transmitter to factory or authorized service station for service. |
|
Too many
obstacles between the receiver and transmitter. |
Move the
obstacles or move the receiver away from nearby metal objects. |
|
Signal
Interference. |
Another
wireless microphone operating on the same frequency |
Use a wireless
microphone with different operating frequency. |
|
Placement too
close to a digital signal processor or similar device (CD player,
stage lighting, etc.). |
1.
Select another operating frequency
2.
Move receiver to another location |
|
External
electromagnetic field source |
|
|
Distortion. |
Low transmitter
battery level |
Replace
transmitter batteries. |
|
AF Level
control on the transmitter set too high, overloading the receiver
circuit. |
Turn down the
AF Level control on the transmitter. |
|
Volume control
on the receiver set too high, overloading the subsequent sound
device input. |
Turn down the
volume control on the receiver. |
|
Momentary loss
of sound when transmitter is moved around the performing area. |
Radio frequency
(RF) blind spots. |
Reposition the
receiver. If the momentary loss of sound problem cannot be removed,
walk through the performing area and mark “Blind” spots. Avoid
these “Blind” spots during performance. |
|
Low sound
level. |
Faulty cable
connection. |
|
|
Receiver volume
control set too low. |
|
|
Sound levels
between two microphones are different. |
The receiver
volume control and/or the microphone AF Level control need to be
adjusted. |
1.
Adjust the transmitter gain control as necessary.
|
Back to Top
|
