(I) Four-Conductor Speaker Cables

ADC280A
16AWG, 4 Conductors
 Cable Spec: (7*17/0.12BC + PV
C2.7)*4C + PVC8.5
Cable Length: 330ft (100M)
Cable Thickness: 8.5mm

ADC280B
14AWG, 4 Conductors
 Cable Spec: (7*27/0.12BC + PVC3.1)*4C + PVC9.5
Cable Length: 330ft (100M)
Cable Thickness: 9.5mm




(II) Two-Conductor Speaker Cables

ADC2803
12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 330ft (100M)
Cable Thickness: 9.0mm

ADC2804
14AWG

Cable Spec: (7/27/0.12*2C)
Cable Length: 330ft (100M)
Cable Thickness: 8.0mm

ADC2805
16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 330ft (100M)
Cable Thickness: 7.0mm

ADC2807
10AWG, Flat-Cable
Cable Spec: (7/17/0.12*4C)*2F
Cable Length: 330ft (100M)
Cable Thickness: 3mm*18mm

Back to Top

ADC2808
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 500ft
Cable Thickness: 8.0mm


ADC2808A
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 1,000ft
Cable Thickness: 8.0mm


ADC2809
16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 500ft
Cable Thickness: 7.0mm



ADC2809A
16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 1,000ft
Cable Thickness: 7.0mm





ADC2811
12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 100ft
Cable Thickness: 9.0mm

Back to Top

ADC2812
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 100ft
Cable Thickness: 8.0mm

ADC2813
16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 100ft
Cable Thickness: 7.0mm

ADC2814
10AWG, Transparent

Cable Spec: (7/7/10/0.12)*2F
Cable Length: 100ft

ADC2815
12AWG, Transparent

Cable Spec: (7/42/0.12)*2F
Cable Length: 100ft

ADC2816
14AWG, Transparent

Cable Spec: (7/27/0.12)*2F
Cable Length: 100ft

ADC2817
16AWG, Transparent

Cable Spec: (7/17/0.12)*2F
Cable Length: 100ft

Back to Top

ADC2818
18AWG, Transparent

Cable Length: 100ft

ADC2821
12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 50ft
Cable Thickness: 9.0mm


ADC2822
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 50ft
Cable Thickness: 8.0mm

ADC2823
16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 50ft
Cable Thickness: 7.0mm

ADC2824
10AWG, Transparent

Cable Spec: (7/7/10/0.12)*2F
Cable Length: 50ft

ADC2825
12AWG, Transparent

Cable Spec: (7/42/0.12)*2F
Cable Length: 50ft

Back to Top

ADC2826
14AWG, Transparent

Cable Spec: (7/27/0.12)*2F
Cable Length: 50ft

ADC2827
16AWG, Transparent

Cable Spec: (7/17/0.12)*2F
Cable Length: 50ft

ADC2828
18AWG, Transparent

Cable Length: 50ft

ADC2831/20
12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 100ft
Cable Thickness: 9.0mm
Configuration: 1/4" to 1/4"

ADC2832/10
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 50ft
Cable Thickness: 8.0mm
Configuration: 1/4" to 1/4"

ADC2832/5
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 25ft
Cable Thickness: 8.0mm
Configuration: 1/4" to 1/4"

Back to Top

ADC2833/5
16AWG

Cable Spec: (7*17/0.12BC + PVC2.7) * 2C + PVC7.0
Cable Length: 25ft
Cable Thickness: 7.0mm
Configuration: 1/4" to 1/4"


ADC2834/20
12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 100ft
Cable Thickness: 9.0mm
Configuration: XLR Male to XLR Female

ADC2835/10
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 50ft
Cable Thickness: 8.0mm
Configuration: XLR Male to XLR Female

ADC2837/20

12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 100ft
Cable Thickness: 9.0mm
Configuration: Banana to 1/4"

ADC2838/10
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 50ft
Cable Thickness: 8.0mm
Configuration: Banana to 1/4"

ADC2838/5
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 25ft
Cable Thickness: 8.0mm
Configuration: Banana to 1/4"

Back to Top

ADC2839/5
16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 25ft
Cable Thickness: 7.0mm
Configuration: Banana to 1/4"

ADC283A/20
12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 100ft
Cable Thickness: 9.0mm
Configuration: 1/4" to XLR Female

ADC283B/10
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 50ft
Cable Thickness: 8.0mm
Configuration: 1/4" to XLR Female

ADC283B/5
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 25ft
Cable Thickness: 8.0mm
Configuration: 1/4" to XLR Female

ADC283C/5
16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 25ft
Cable Thickness: 7.0mm
Configuration: 1/4" to XLR Female

ADC283D/20
12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 100ft
Cable Thickness: 9.0mm
Configuration: Banana to XLR Female

ADC283E/10
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 50ft
Cable Thickness: 8.0mm
Configuration: Banana to XLR Female


ADC283F/5
16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 25ft
Cable Thickness: 7.0mm
Configuration: Banana to XLR Female

ADC283G/20
12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 100ft
Cable Thickness: 9.0mm
Configuration: Speakon Male (2 Pins) to 1/4"

ADC283H/10
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 50ft
Cable Thickness: 8.0mm
Configuration: Speakon Male (2 Pins) to 1/4"

ADC283J/5

16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 25ft
Cable Thickness: 7.0mm
Configuration: Speakon Male (2 Pins) to 1/4"

ADC283M/5
16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 25ft
Cable Thickness: 7.0mm
Configuration: Speakon Male (2 Pins) to XLR Male

Back to Top

ADC283N/20

12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 100ft
Cable Thickness: 9.0mm
Configuration: Speakon Male (2 Pins) to Banana

ADC283P/10

14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 50ft
Cable Thickness: 8.0mm
Configuration: Speakon Male (2 Pins) to Banana

ADC283R/5

16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 25ft
Cable Thickness: 7.0mm
Configuration: Speakon Male (2 Pins) to Banana

ADC283S/20
12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 100ft
Cable Thickness: 9.0mm
Configuration: Speakon Male (2 Pins) to Speakon Male (2 Pins)

ADC283T/10
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 50ft
Cable Thickness: 8.0mm
Configuration: Speakon Male (2 Pins) to Speakon Male (2 Pins)

ADC283U/5

16AWG

Cable Spec: (7*17/0.12BC + PVC2.7) * 2C + PVC7.0
Cable Length: 25ft
Cable Thickness: 7.0mm
Configuration: Speakon Male (2 Pins) to Speakon Male (2 Pins)

Back to Top

ADC283Y/20
12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 100ft
Cable Thickness: 9.0mm
Configuration: Speakon Female (2 Pins) to Speakon Female (2 Pins)

ADC283Z/10
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 50ft
Cable Thickness: 8.0mm
Configuration: Speakon Female (2 Pins) to Speakon Female (2 Pins)

ADC2840/5
16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 25ft
Cable Thickness: 7.0mm
Configuration: Speakon Female (2 Pins) to Speakon Female (2 Pins)

ADC2841/20
12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 100ft
Cable Thickness: 9.0mm
Configuration: Speakon Female (2 Pins) to Speakon Male (2 Pins)

ADC2842/10
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 50ft
Cable Thickness: 8.0mm
Configuration: Speakon Female (2 Pins) to Speakon Male (2 Pins)

ADC2843/5
16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 25ft
Cable Thickness: 7.0mm
Configuration: Speakon Female (2 Pins) to Speakon Male (2 Pins)

Back to Top

ADC2844/20
12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 100ft
Cable Thickness: 9.0mm
Configuration: Speakon Male (2 Pins) to 1/4"

ADC2845/10
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 50ft
Cable Thickness: 8.0mm
Configuration: Speakon Male (2 Pins) to 1/4"

ADC284A/20
12AWG

Cable Spec: (7/42/0.12*2C)
Cable Length: 100ft
Cable Thickness: 9.0mm
Configuration: Banana to Banana

ADC284B/10
14AWG
Cable Spec: (7/27/0.12*2C)
Cable Length: 50ft
Cable Thickness: 8.0mm
Configuration: Banana to Banana

ADC284C/10
16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 50ft
Cable Thickness: 7.0mm
Configuration: Banana to Banana

ADC284C/5
16AWG

Cable Spec: (7/17/0.12*2C)
Cable Length: 25ft
Cable Thickness: 7.0mm
Configuration: Banana to Banana



Back to Top
